Ice Bath Chiller

ZN's ice bath chiller machines feature fast cooling, smart WiFi control, UV water cleaning, low noise, and a portable design. We've already shipped them to over 50 countries!

ZN - Trust Ice Bath Chiller Manufacturer in China

An ice bath chiller machine is a cooling device for cold water therapy. It usually connects to a cold plunge tub or you can connect it to your home bathtub to easily create your own ice bath, quickly chilling the water to 3°C-15°C in hours. People use it for muscle recovery, reducing swelling, or boosting health.

The cooling principle of an ice bath machine is exactly the same as an air-source heat pump in cooling mode. Simply put, it constantly absorbs heat from the water through a process where refrigerant is compressed, condensed, expanded, and evaporated, then transfers that heat “out” into the air outside the machine, making the water icy cold.

ZN boasts 15 years of air source technology expertise, ensuring highly efficient cooling and stable performance with various customization options. We offer rapid response to client needs, ensuring a short design-to-mass production cycle ideal for brand product development.

ZN Chiller for Ice Bath and Cold Plunges

ZN Ice Bath Chiller Specifications
ModelZNLSP-30R/S3N2-HYZNLSP-30R/N8-HY
Power Supply115V/1Ph/60Hz230V/1Ph/50Hz
Cooling Capacity2.702 kW2.788 kW
Rated Input Power0.932 kW0.955 kW
COP2.92.92
Water Temperature Range3-40 °C3-40 °C
RefrigerantR410aR32
Noise Level53 dB(A)52 dB(A)
Compressor BrandGMCCPanasonic
Compressor Power2.99 kW2.99 kW
Water Heat ExchangerTitanium PVC TankTitanium PVC Tank
Water Flow1.7 m³/h1.7 m³/h
Water Inlet/Outlet Size3/4"3/4"
Cooling Time (23°C to 12°C)200L @ 1.6h
500L @ 4.0h
1000L @ 7.9h
200L @ 1.5h
500L @ 3.9h
1000L @ 7.7h
Cooling Time (23°C to 5°C)200L @ 3.3h
500L @ 8.8h
1000L @ 17.5h
200L @ 3.2h
500L @ 8.7h
1000L @ 17.2h
Control DisplayLCD, Touch PanelLCD, Touch Panel
FeaturesCooling, Wifi, Water Filter, Circulation Pump, UV Disinfection, Carry Handle, Transport WheelsCooling, Wifi, Water Filter, Circulation Pump, UV Disinfection, Carry Handle, Transport Wheels
Expansion ValveElectronicElectronic
Net Weight33 kg34 kg
Gross Weight39 kg40 kg
Product Dimensions (W*D*H)430*662*528 mm430*662*528 mm
Packing Dimensions (W*D*H)470*850*570 mm470*850*570 mm
Notice: The above data is for reference only, The specs data is subject to actual product

Professional Ice Bath Chiller Manufacturer

As a ice bath chiller manufacturer, ZN offers extensive customization options including branded logos, body colors, materials, cooling capacities, control system interfaces, machine dimensions, and tailored fittings.Furthermore, for bulk purchases, we are able to provide highly competitive pricing.

FAQ

Most chillers operate around 3°C above freezing to avoid actual ice formation, as freezing would disrupt the system

Yes, but larger volumes require more powerful chillers designed for higher capacity

Monthly replacement is recommended to maintain optimal water flow and prevent damage
